CAUTION!!! Package doesn't include power supply!!!
• High quality imaging with 5 MP, 2560 × 1944 resolution
• 2.8 mm, 3.6 mm, 6 mm fixed focal lens
• Up to 40 m IR distance for bright night imaging
• One port for four switchable signals (TVI/AHD/CVI/CVBS)
• Water and dust resistant (IP67)
• High quality audio with audio over coaxial cable, built-in mic
Warranties - Returns: | |
Money Return: | Repair - Replacement: |
20 days | 36 months |
Specifications | |
Camera | |
Image Sensor | 5 MP CMOS |
Signal System | PAL/NTSC |
Resolution | 2560 (H) × 1944 (V) |
Frame Rate | TVI: 5 MP @ 20 fps, 4 MP @ 30 fps, 4 MP @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps AHD: 5 MP @ 20 fps, 4 MP @ 30 fps, 4 MP @ 25 fps CVI: 4 MP @ 30 fps, 4 MP @ 25 fps CVBS: PAL/NTSC |
Min. Illumination | 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shutter Time | PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
Lens | 2.8 mm fixed focal lens |
Field of View | horizontal FOV: 85°, vertical FOV: 63°, diagonal FOV:110° |
Lens Mount | M12 |
Day & Night | ICR |
WDR (Wide Dynamic Range) | Digital WDR |
Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360° |
Menu | |
Image Mode | STD/HIGH-SAT |
AGC | Yes |
Day/Night Mode | Auto/Color/BW (Black and White) |
White Balance | Auto/Manual |
AE (Auto Exposure) | DWDR, BLC, HLC, Global |
Noise Reduction | 2D DNR |
Language | English |
Function | Brightness, Mirror, Smart IR, Sharpness |
Interface | |
Video Output | Switchable TVI/AHD/CVI/CVBS |
Audio In | Built-in mic |
General | |
Operating Conditions | -40°C to 60°C, Humidity: 90% or less (non-condensing) |
Power Supply | 12 VDC ± 25% |
Consumption | Max. 4.5 W |
Protection Level | IP67 |
Material | Front cover: Metal, Main body: Plastic |
IR Range | Up to 40 m |
Communication | HIKVISION-C |
Dimension | 78.9 mm × 75.4 mm × 216.6 mm |
Weight | Approx. 338 g |
