Netio PowerPDU 8QS, 8x IEC-320 C13 switched and metered PDU

Product Code:
558089
Manufacturer Netio
Sales price: 485,00 €(Includes 24% VAT)
Sales price without TAX:391,13 €
Product Availability:

Show Shipping Cost:
  • Description
  • Specifications
  • Downloads
  • Reviews
Netio PowerPDU 8QS, 8x IEC-320 C13 switched and metered PDU

PowerPDU 8QS is a PDU (Power Distribution Unit) with eight power outputs (8x IEC-320 C13) controlled and metered over a LAN. It fits into a 19" cabinet (1U). Each output can be switched on/off individually over the web interface, NETIO Cloud service or the mobile app. Open API enables integration into a third party systems. Electrical metering is performed on two channels - whole PDU (at the input) and Output1 separately. DI (Digital Input) can control the outputs or count S0 pulses and is available through API.
Each of eight outputs can be independently controlled from the web interface (switched on / off or power-cycled). To switch the outputs on in a sequence (after a power-up or when power is restored), a power-up delay interval can be configured for each output individually.
NETIO PowerPDU 8QS fits into 19" cabinet (1U). A metal bracket is included.
The NETIO Mobile2 app controls each output individually over LAN (local network) or NETIO Cloud.
NETIO Cloud is a SSL-secured service for controlling multiple devices from anywhere (Web or Cloud API).
Open API (such as XML/JSON over HTTP, SNMP, Modbus/TCP, MQTT-flex, Telnet and others...) enables integration with third party systems (controlling the outputs over the network).
DI (Digital Input) can be for example connected to a button or used as a S0 pulse counter for reading energy consumption from an external electricity meter. Its state is available through API.
AV drivers make it easy to connect NETIO sockets to a professional Audio/Video control systems such as Neets, Crestron, Control4, RTI, Savant and more.
Electrical values are measured with high accuracy for a whole PDU (at the input) and for Output1.

Features:
• LAN (Ethernet)
• Input: IEC-320 C20 110/230V (max 16A)
• Output: 8x IEC-320 C13 (max 10A / output)
• Electrical metering: Whole PDU + Output1
• Open API (10 protocols, M2M API)
• Mobile app: NETIO Mobile2
• Service: NETIO Cloud

Warranties - Returns:
Money Return: Repair - Replacement:
20 days 24 months
Specifications
Power Power input: IEC-320 C20 (110/230V AC), max 16A
Power output: 8x IEC-320 C13, max 10A each
Each output: On/Off (relay SPST-NO, IOC)
ZVS (Zero Voltage Switching): Yes
Internal consumption: 1-3 W
PowerUp State: Default output state (On/Off/Last state)
PowerUp Delay: Delay before switching output on
Interfaces LAN 10/100 Mbps (RJ-45)
1x DI (Digital Input) with 12V DC (max 50mA)
LED indicators in the RJ45 jack & M2M LED
Electrical Measurments
(Whole PDU + Output1)
Current [A]
Consumption [Wh]
Power [W]
TPF (True Power Factor)
Accuracy: <1%
Phase [°]
Frequency [Hz]
Voltage [V]
Reverse Energy [Wh]
Dimensions 439 x 41 x 90 mm
Protection IP30
Temperature range -20 °C to 50 °C
Standards EN 62368, EN 60950, EN61000, EN50581
Package contents NETIO PowerPDU 8QS
QIG (printed Quick Installation Guide)
Metal brackets to 19" cabinet (1U) + screw set
Power cord
