GENERAL | |
Insulation material | PA66 |
Contact material | Copper alloy |
Contact finishing | Tin-plated |
Wire cross section | 0.2-1.5mm2 (24-16AWG) |
Pitch | 3.5 mm |
Temperature range | -40 +105 |
ADDITIONAL | |
Rated voltage | 300 V |
Rated current | 8 A |
Dielectric voltage-withstand | 1600V/1min |
Strip Length | 9 - 10mm |
Certification | RoHS,REACH,UL94V-0 |
