• 24 10/100Mbps Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
• Green Ethernet technology saves power consumption
• IEEE 802.3x flow control provides reliable data transfer
• Plastic case, desktop or wall-mounting design

What This Product Does
The TL-SF1024M Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. All 24 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1024M can save power consumption, making it an eco-friendly solution for your business network.

TP-LINK Green Technology
This new generation TL-SF1024M Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials.

High Performance
TL-SF1024M Fast Ethernet Switch provides 24 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. Featuring non-blocking switching architecture, TL-SF1024M forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1024M work reliably.

Easy of Use
The auto features of this switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance..

Features
• Up to 200 Mbps full duplex bandwidth for high-speed data processing

• 24 10/100 Mbps Ethernet ports

• Auto MDI/MDIX eliminates the need for crossover cables

• Auto-Negotiation ports provide smart integration between 10 Mbps and 100 Mbps hardware

• IEEE 802.3x flow control provides reliable data transfer

• Green Ethernet technology saves power consumption

• Plug and play design simplifies installation

Warranties - Returns:
Money Return:	Repair - Replacement:
20 days	36 months

SPECIFICATIONS
Standards	IEEE 802.3, IEEE802.3u, IEEE802.3x
Interface	24 10/100 Mbps RJ45 PortsAUTO Negotiation/AUTO MDI/MDIX
Forwarding Mode	Store-and-Forward
Fan Quantity	Fanless
Green Technology	Yes
Power Consumption	Maximum: 3.36 W (220 V/50 Hz)
Power Supply	External Power Adapter (Output: 9 V/0.6 A)
LEDs	Power, Ethernet Ports (1-24)
Dimensions (WxDxH)	222 x 126 x 45 mm
Switching Features	Half and Full Duplex MAC Address Learning 4.8 Gbps Switching Capacity
Forwarding Rates	10BASE-T: 14880 pps/port 100BASE-TX: 148800 pps/port
Data Rates	10/100 Mbps at Half Duplex 20/200 Mbps at Full Duplex
MAC Address Table	8k
Jumbo Frame	2KB
Certifications	CE, FCC, RoHS
Operating Temperature	0°C–40°C
Storage Temperature	-40°C–60°C
Operating Humidity	10%–90%RH non-condensing
Storage Humidity	5%–90%RH non-condensing
