2× 2.5 Gbps RJ45 ports (1× WAN, 1× WAN/LAN)
5× Gigabit WAN/LAN ports (1× SFP, 4× RJ45)
Load Balancing on up to 6 WAN ports^‡ increases the utilization rate of multi-line broadband
1× USB port (Supports USB storage, and LTE backup with LTE dongle)
High-security SSL/ IPSec / GRE^§ / WireGuard / PPTP / L2TP VPN & OpenVPN
Centralized cloud management via the web or the Omada app*
DoS/DDoS protection, IP/MAC/URL filtering, DPI, and IPS/IDS for enhanced security
Rackmount, Desktop, or Wall Mount

Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.

High-Security and High-Performance VPN
SSL/ IPSec / GRE / WireGuard / PPTP / L2TP VPN & OpenVPN easily build secure VPN tunnels for secure Internet browsing, communication between different branches, or enabling remote work or study from home.

Warranties - Returns:
Money Return:	Repair - Replacement:
20 days	60 months

Specifications
General
CPU	Dual-core ARMv8
Interface	1× 2.5G RJ45 WAN Port 1× 2.5G RJ45 WAN/LAN Port 1× Gigabit SFP WAN/LAN Port 4× Gigabit RJ45 WAN/LAN Ports
USB	1 USB2.0 (Supports LTE backup with LTE dongle, and USB Storage)
Button	Reset button
Power Supply	12V / 1.5A Adapter
Flash	128 MB NAND
DRAM	1 GB DDR4
Surge Protection	4 kV surge protection
Max Power Consumption	14.2 W (with USB2.0 connected) 7.1 W (without USB2.0 connected)
Dimensions ( W x D x H )	226 × 131 × 35 mm
SDN Support
Hardware Controller (OC200/ OC300) Software Controller Cloud-Based Controller	Automatic Device Discovery Intelligent Network Monitoring Abnormal Event Warnings Unified Configuration Reboot Schedule Captive Portal Configuration ZTP (Zero-Touch Provisioning)
Performance
Concurrent Session	500,000
New Sessions /Second	6,000
IPS Throughput	TCP: 208 Mbps UDP: 161 Mbps
DPI Throughput	TCP: 1823 Mbps UDP: 1272 Mbps
Static IP NAT Throughput (Upload / Download)	2365.17 Mbps / 2364.45 Mbps
DHCP NAT Throughput (Upload / Download)	2364.45 Mbps / 2366.04 Mbps
PPPoE NAT Throughput (Upload / Download)	2347.14 Mbps / 2348.29 Mbps
L2TP NAT Throughput (Upload / Download)	1308.86 Mbps / 974.10 Mbps
PPTP NAT Throughput (Upload / Download)	1236.27 Mbps / 1280.99 Mbps
66 Byte Packet forwarding rate (Upload / Download)	1832.69 Mbps / 1741.84 Mbps
1,518 Byte Packet forwarding rate (Upload / Download)	2461.18 Mbps / 2457.32 Mbps
SSL VPN Throughput	132.24 Mbps
GRE VPN Throughput	286.84 Mbps
IPSec VPN Throughput	ESP-SHA1-AES256: 673.3 Mbps, ESP-SHA256-AES256: 650.2 Mbps ESP-SHA384-AES256: 629.3 Mbps, ESP-SHA512-AES256: 633.8 Mbps
L2TP VPN Throughput	Unencrypted: 1243.7 Mbps; Encrypted: 561.0 Mbps
OpenVPN Throughput	135.0 Mbps
Wireguard VPN Throughput	343Mbps
Basic Functions
WAN Connection Type	IPv4_Static IP IPv4_Dynamic IP IPv4_PPPOE IPv4_L2TP IPv4_PPTP IPv6_PPP IPv6_DHCPv6 IPv6_Static IP IPv6_6in4 IPv6_Pass-Through Mobile Broadband: 4G/3G modem for backup via USB port
DHCP	DHCP Server DHCPv6 PD Server (only in Standalone Mode) DHCP Options Customization DHCP Address Reservation Multi-IP Interfaces Multi-Net DHCP
MAC Clone	Modify WAN/LAN MAC Address
IPTV	IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
IPv6	StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / NonAddress mode
Stateful ACL	√
mDNS Repeater	√
Quality of Service	√
Bridge VLAN	√
VLAN	802.1Q VLAN
Transmission
Load Balance	Intelligent Load Balance Application Optimized Routing Link Backup (Timing, Failover) Online Detection
NAT	One-to-One NAT Multi-Net NAT Virtual Server Port Triggering NAT-DMZ FTP/H.323/SIP/IPSec/PPTP ALG UPnP
Routing	Static Routing Policy Routing RIP (only in Standalone Mode) OSPF (only in Standalone Mode)
Session Limit	IP-based Session Limit
Bandwidth Control	IP/Port-based Bandwidth Control Guarantee & Limited Bandwidth
VPN
SSL VPN	SSL VPN Server 60 SSL VPN Tunnels
IPSec VPN	100 IPSec VPN Tunnels LAN-to-LAN, Client-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, SHA1, AES128, AES192, AES256 Encryption Algorithm IKE v1/v2 MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS)
GRE	Only in Standalone Mode
WireGuard VPN	√
PPTP VPN	PPTP VPN Server PPTP VPN Client (12) 60 Tunnels (Shared with L2TP) PPTP with MPPE Encryption
L2TP VPN	L2TP VPN Server L2TP VPN Client (12) 60 Tunnels (Shared with PPTP) L2TP over IPSec
OpenVPN	OpenVPN Server OpenVPN Client (6) 66 OpenVPN Tunnels
Security
Attack Defense	TCP/UDP/ICMP Flood Defense Block TCP Scan (Stealth FIN/Xmas/Null) Block Ping from WAN
Filtering	Web Group Filtering URL Filtering Web Security
DNS Proxy	DNSSEC, DoH, and DoT
ARP Inspection	Sending GARP Packets ARP Scanning IP-MAC Binding
Access Control	Source/Destination IP Based Access Control
Authentication
Web Authentication	No Authentication Simple Password Hotspot (Local User / Voucher / SMS / Radius) External Radius Server External Portal Server LDAP³
Management
Service	Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)
Maintenance	Web Management Interface Remote Management Export & Import Configuration SNMP v1/v2c/v3 Diagnostics (Ping & Traceroute) NTP Synchronize Port Mirroring CLI (only in Standalone Mode) Syslog Support
Others
Certification	CE, FCC, RoHS
Package Contents	ER707-M2 Power Adapter Rackmount Kit Quick Installation Guide
System Requirements	Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10 MAC OS, NetWare, UNIX or Linux
Environment	Operating Temperature: 0 °C to 40 °C Storage Temperature: -40 °C to 70 °C Operating Humidity: 10% to 90% non-condensing Storage Humidity: 5% to 90% non-condensing
